1 cold store

A warehouse complex with artificial refrigeration and cold insulation, including refrigerating machine rooms, transformer and distribution rooms, etc.

2 storehouseRefers to the main body of the cold storage building and the auxiliary rooms such as staircases, elevators, and hallways serving it.

3 pass through the anteroom

Aisles set up for the entry and exit of goods in the cooling room, freezing room, and cold storage room. The room temperature is divided into normal temperature or a specific temperature.

4 cold room

The general term for rooms that use artificial refrigeration in cold storage, including cooling time, freezing room, cold storage room, ice room, low-temperature hall, etc.

5 cooling room

Room for cooling and processing products

6 freezing room

The room where the product is frozen and processed

7 cold storage room

The cold room used to store cold processed products, among which the cold room used to store cold processed products is called the chilled object cold room; the cold room used to store frozen processed products is called the frozen object cold room

8 ice storage room

Room for storing ice

9 refrigerating machine room

General term for refrigeration machine room and equipment room

10 machine room

The room where the refrigeration compressor is installed

11 equipment room

Room where cooling auxiliary equipment is installed

12 Cooling equipment load

In order to maintain the cold room at a certain temperature, the heat flow value that needs to be removed from the cold room.

13 mechanical load

In order to maintain the normal operation of the refrigeration system, the heat flow value taken away by the refrigeration compressor load.

14 Refrigerating system

The refrigeration machinery and equipment and related components are connected to each other through pipes to form a closed refrigeration circuit in which the refrigerant circulates to absorb and release heat.

15 Keep to the cooling

Technical measures taken to prevent condensation on the outer surface of low-temperature equipment and pipelines to reduce their cold loss
